The Centerforce(R) DFX(R) Clutch Series is SFI approved and brings together various reinforcements and patenteds technologies for a great race-inspired single disc clutch.
this can cause some additional drive train noise and/or chatter.
Application Summary:
| Year |
Make/Model |
| 1993-1997 |
Chevrolet Camaro |
| 1993-1997 |
Pontiac Firebird |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Bolt Pattern |
24, 24, 24 |
| Clutch Disc Diameter |
11, 11, 11, 279.4 |
| Counterweight Assist |
YES, YES |
| Country of Origin (Primary) |
US |
| Disc Material |
Cerametallic, Cerametallic |
| Disc Type |
6-Paddle, 6-Paddle |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Input Shaft Diameter |
1-1/8, 1-1/8 |
| Input Spline Quantity |
26, 26 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Cast Iron Pressure Plate / Cerametallic Button Style Friction, Cast Iron Pressure Plate / Cerametallic Button Style Friction, Cast Iron Pressure Plate / Cerametallic Button Style Friction |
| Mounting Hardware Included |
Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Release Bearing Included |
Yes, Yes |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
Y, Y, Y |
| Warranty Time |
12 |
| GTIN |
00788442032604 |
