The Centerforce(R) SST (Solid Street Twin) 10.4 Inch multi-disc clutch offers smooth engagement, light pedal, and high-end holding capacity for engine torque levels from 400 to 925 ft /lbs.
Introducing the NEW Centerforce(R) SST (Solid Street Twin). The SST clutch system has been engineered and developed for vehicles producing 400 to 925 ft/lbs of torque. The SST 10.4" discs utilize solid hubs (possible gear noise) to reduce the rotational weight on the input shaft for quick clean shifts. The discs in this assembly are built using high quality friction materials, for smooth engagement and longevity. The SST features a lightened billet steel flywheel, providing low inertia resulting in quicker RPM and the Centerforce anti-rattle system to reduce floater rattle/noise. No complicated setup or adjustments required, just bolt it in and "Get a Grip". The Centerforce SST includes a billet steel flywheel, 2 discs, floater plate, pressure plate, pilot bearing, alignment tool, and ARP pressure plate and flywheel hardware. The SST clutch system is an economical choice for streetcar enthusiasts looking for a complete high-quality twin disc clutch system. This new clutch assembly can be used for everyday use and spirited days on the track.

Application Summary:

Year Make/Model
1970-1972 Chevrolet Chevelle
1970-1974 Chevrolet Corvette
1970-1974 Chevrolet El Camino
1970-1974 Chevrolet Monte Carlo
1971-1974 GMC Sprint
Attributes
Alignment Tool Included Yes, Yes
California Proposition 65 WARNING: Cancer - www.P65Warnings.ca.gov
Clutch Disc Diameter 10.4, 10.4, 264.2
Counterweight Assist No, No
Country of Origin (Primary) US
Crankshaft Bolt Hole Quantity 6, 6
Disc Material Organic, Organic
Disc Quantity 2, 2
Disc Type Full Face, Full Face
Disc Type Sprung Solid Solid, Solid
Emission Code Legal US
Flywheel Counter Balance Weight 33, 33
Flywheel Crank Bolt Size 7/16 in x 20 x 0.875, 7/16 in x 20 x 0.875
Flywheel Crank Flange Register 2.485, 2.485
Harmonized Tariff Code (Schedule B) 8708935000
Hazardous Material Code N
Input Shaft Diameter 1-1/8, 1-1/8
Input Spline Quantity 26, 26
Life Cycle Status Code Available to Order
Made In The USA Assembled, Assembled
Material Billet Steel Flywheel / Nodular Iron Pressure Plate / Organic Friction, Billet Steel Flywheel / Nodular Iron Pressure Plate / Organic Friction
Mounting Hardware Included Yes, Yes
NAFTA Preference Criterion Code B
Out of Package Weight 45.70
Pilot Bushing Included Yes, Yes
Rear Main Seal Style 2, 2
Ring Gear O.D 14.096
Ring Gear O.D. 14.105, 14.105
Ring Gear Tooth Count 168
SDR Required Flag N
Tooth Quantity 168, 168
Torque Capacity 925, 925
Warranty Time 12
GTIN 00788442036213
