The Centerforce(R) DYAD(R) XDS (eXtreme Drive System) 10.4 Inch patented multi-disc clutch offers smooth engagement, light pedal, and high-end holding capacity for engine torque levels from 700 to 1600 ft /lbs.
The Centerforce(R) DYAD XDS 10.4" twin disc clutch has been developed for vehicles requiring a holding capacity of 700 to 1600 ft/lbs of torque at the crank. The pressure plate features our patented centrifugal weight system for superior clamp load over stock and our patented ball bearing actuated pressure plate providing light pedal effort. The discs are equipped with metallic paddle/button style friction material providing increased holding capacity. DYAD XDS clutches are equipped with a lightened billet steel flywheel providing low inertia resulting in quicker RPM's. Due to the aggressive nature of this race inspired clutch, vehicles may experience some floater noise and/or chatter during operation. Components are designed, machined and assembled in the USA. DYAD XDS clutches are match balanced and ready for installation using the included ARP fasteners.
Application Summary:
| Year |
Make/Model |
| 2003-2006 |
Dodge Viper |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
10.4, 10.4, 264.2 |
| Counterweight Assist |
YES, Yes |
| Country of Origin (Primary) |
US |
| Crankshaft Bolt Hole Quantity |
8, 8, 8 |
| Disc Material |
Cerametallic, Cerametallic |
| Disc Type |
6-Paddle, 6-Paddle |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Flywheel Crank Bolt Size |
7/16 in x 20 x 0.875, 7/16 x 20, 7/16 in x 20 x 0.875 |
| Flywheel Crank Flange Register |
2.159, 2.159, 2.159 |
| Flywheel Deck Height |
3.550, 3.55 |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Input Shaft Diameter |
1-1/8, 1-1/8 |
| Input Spline Quantity |
26, 26 |
| Installed Height |
3.550, 3.550 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Billet Steel Flywheel / Aluminum Pressure Plate / Cerametallic Button Style Friction, Billet Steel Flywheel / Aluminum Pressure Plate / Cerametallic Button Style Friction |
| Mounting Hardware Included |
Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Out of Package Weight |
48.20 |
| Outside Diameter |
14.568 |
| Pilot Bushing Included |
Yes, Yes |
| Ring Gear O.D |
14.568 |
| Ring Gear O.D. |
14.579, 14.579 |
| Ring Gear OD |
14.568 |
| Ring Gear Tooth Count |
143 |
| SDR Required Flag |
N |
| Tooth Quantity |
143, 143 |
| Torque Capacity |
1600, 1600 |
| Warranty Time |
12 |
| GTIN |
00788442032529 |
