Centerforce(R) brings together high-quality friction materials and patented processes to give you top-of-the-line discs.
The Centerforce(R) Dual Friction(R) Disc Series uses a single disc with patented dual friction technology by distributing pressure plate clamp force evenly over a 360-degree friction-facing on one side of the clutch disc, while the opposing side uses a segmented friction-facing to concentrate clamping pressure and increase clutch holding-capacity. These discs are made for Centerforce Dual Friction pressure plates.
Application Summary:
| Year |
Make/Model |
| 1963-1969 |
Ford Fairlane |
| 1964-1970 |
Ford Falcon |
| 1967 |
Ford Galaxie |
| 1968-1971 |
Ford Galaxie 500 |
| 1975-1980 |
Ford Granada |
| 1973-1977 |
Ford Maverick |
| 1964-1973 |
Ford Mustang |
| 1982-1985 |
Ford Mustang |
| 1970-1971 |
Ford Ranchero |
| 1969-1973 |
Ford Torino |
| 1963-1964 |
Mercury Comet |
| 1966-1969 |
Mercury Comet |
| 1971-1977 |
Mercury Comet |
| 1967-1969 |
Mercury Cougar |
| 1969-1973 |
Mercury Montego |
| 1978-1979 |
Mercury Zephyr |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
10, 10, 254.0 |
| Country of Origin (Primary) |
US |
| Disc Material |
Organic/Carbon composite, Organic/Carbon composite, Organic/Carbon composite |
| Disc Type |
Full face/Segmented face, Full face/Segmented face, Full face/Segmented face |
| Disc Type Sprung Solid |
Sprung, Sprung |
| Emission Code |
Legal US |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
DISC |
| Input Shaft Diameter |
1-1/8, 1-1/8 |
| Input Spline Quantity |
26, 26 |
| Inside Diameter of Friction Surface |
6.300, 6.300, 160.0 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Full Face and Segmented Organic Friction, Full Face and Segmented Organic Friction |
| NAFTA Preference Criterion Code |
B |
| Out of Package Weight |
3.40, 3.35, 3.40 |
| Outside Diameter of Friction Surface (Standard) |
10" |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
N |
| Warranty Time |
12 |
| GTIN |
00788442030631 |
