Centerforce(R) brings together high-quality friction materials and patented processes to give you top-of-the-line discs.

The Centerforce(R) Dual Friction(R) Disc Series uses a single disc with patented dual friction technology by distributing pressure plate clamp force evenly over a 360-degree friction-facing on one side of the clutch disc, while the opposing side uses a segmented friction-facing to concentrate clamping pressure and increase clutch holding-capacity. These discs are made for Centerforce Dual Friction pressure plates.

Application Summary:

Year	Make/Model
1971-1974	DeTomaso Pantera
1981-1989	DeTomaso Pantera
1952-1953	Ford Courier Sedan Delivery
1963-1969	Ford Fairlane
1979	Ford Fairmont
1964-1970	Ford Falcon
1967	Ford Galaxie
1968-1971	Ford Galaxie 500
1975-1979	Ford Granada
1973-1977	Ford Maverick
1964-1973	Ford Mustang
1979	Ford Mustang
1982-2001	Ford Mustang
1969-1973	Ford Torino
1951-1953	Ford Victoria
1976-1979	Jeep CJ5
1976-1979	Jeep CJ7
1986	Mercury Capri

Attributes
ASIN	B005DJ6ZO8
Attribute Data	2
California Proposition 65	WARNING: Cancer - www.P65Warnings.ca.gov
Clutch Disc Diameter	10.4, 10.4, 264.2
Country of Origin (Primary)	TH
Disc Material	Organic/Carbon composite, Organic/Carbon composite, Organic/Carbon composite
Disc Type	Full face/Segmented face, Full face/Segmented face, Full face/Segmented face
Disc Type Sprung Solid	Sprung, Sprung, Sprung
Emission Code	Legal US
Harmonized Tariff Code (Schedule B)	8708935000
Hazardous Material Code	N
Includes	Disc
Input Shaft Diameter	1-1/16, 1-1/16
Input Spline Quantity	10, 10
Inside Diameter of Friction Surface	6.490, 6.490, 164.8
Life Cycle Status Code	Available to Order
Made In The USA	Assembled, Assembled
Material	Full Face and Segmented Organic Friction, Full Face and Segmented Organic Friction
NAFTA Preference Criterion Code	B
Out of Package Weight	4.49, 4.49
Outside Diameter of Friction Surface (Standard)	10.4
SDR Required Flag	N
Spline Diameter and Tooth Count	1-1/16"-10
Standard Pack	1
Warranty Time	12
GTIN	00788442027556
