The Centerforce(R) LMC Clutch Series is machined from billet aluminum and designed for low inertia, dramatically reducing engine rotating mass.
The Centerforce(R) LMC Clutch Series is a specifically designed low inertia performance clutch that dramatically reduces engine rotating mass. These lightweight, SFI approved competition clutches are intended with most road racing and circle track applications in mind. Centerforce machines these special pressure plates from high-strength aircraft-grade billet aluminum and then attach a special heat-treated replaceable friction surface. The Centerforce LMC series friction disc utilizes a dual-segmented carbon composite lining for improved cooling and excellent torque capacity. Light Metal Clutch assemblies from Centerforce uses their patented 'Ball Bearing' actuated diaphragm and centrifugal weight system for maximum grip while maintaining a comfortable and controllable clutch pedal. When used in conjunction with Centerforce's aluminum flywheels, LMC Series brings the term 'Lightweight' to an unparalleled level!
Application Summary:
| Year |
Make/Model |
| 1999 |
Ford Mustang |
| 2001-2004 |
Ford Mustang |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| ASIN |
B000VU2IMW |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Bolt Pattern |
18, 18 |
| Clutch Disc Diameter |
11, 11, 279.4 |
| Counterweight Assist |
YES, Y, YES |
| Country of Origin (Primary) |
US |
| Disc Material |
Organic/Carbon composite, Organic/Carbon composite |
| Disc Type |
Segmented face, Segmented face |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Pressure Plate, Disc, Alignment tool. |
| Input Shaft Diameter |
1-1/16, 1-1/16 |
| Input Spline Quantity |
10, 10 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Aluminum Pressure Plate / Segmented Organic Friction, Aluminum Pressure Plate / Segmented Organic Friction, Aluminum Pressure Plate / Segmented Organic Friction |
| NAFTA Preference Criterion Code |
B |
| Outside Diameter of Friction Surface (Standard) |
11 |
| Replaceable Friction Surface |
Y, Y |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
Y, Y |
| Spline Diameter and Tooth Count |
1-1/16"-10 |
| Standard Pack |
1 |
| Torque Capacity |
750, 750, 750 |
| Warranty Time |
12 |
| GTIN |
00788442023688 |
