Aluminum radiator engineered for efficient heat dissipation and optimal engine cooling. Precision-fit design ensures easy installation, corrosion resistance, and reliable performance across varied driving conditions.
A Mishimoto performance aluminum radiator is the ideal upgrade to the stock 2006-2011 Honda Civic Si radiator.For a cooler more efficient running engine, all Mishimoto radiators are designed and engineered to maximize cooling, boost engine functions, and most importantly prevent your car from overheating.Made with 100-percent brazed aluminum and polished end tanks, this lightweight two row core radiator will enhance the overall performance and lifetime of your engine.All Mishimoto radiators are backed by a lifetime warranty.Check out the 2006-2011 Civic Si hose kit, for even greater cooling efficiency.
- Full aluminum construction with durable TIG-welded end tanks
- Features a two-row, 1.57-in thick brazed aluminum core which provides efficient fluid temperature regulation on the street and track
- Polished end tanks provide a stylish upgrade to your engine bay
Application Summary:
| Year |
Make/Model |
| 2006-2011 |
Honda Civic |
| Attributes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Core Height |
26.32 |
| Core Length |
14.72 |
| Core Material |
Aluminum |
| Core Row Quantity |
2 |
| Core Thickness |
1.57 |
| Country of Origin (Primary) |
CN |
| Dimensions |
26.8in x 18.2in x 2.07in |
| Down Flow Or Cross Flow Type |
Cross Flow |
| Drain Plug Included |
Yes |
| Fluid Capacity |
2.03 |
| Harmonized Tariff Code (Schedule B) |
8708915000 |
| Hazardous Material Code |
N |
| Inlet Diameter |
1.25 |
| Inlet Location |
Top Left |
| Install Difficulty |
3 |
| Installation Difficulty |
3 |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum |
| NAFTA Preference Criterion Code |
B |
| Outlet Diameter |
1.25 |
| Outlet Location |
Bottom Left |
| Overall Height |
26.8 |
| Overall Length |
18.2 |
| Overall Width |
2.07 |
| Radiator Cap Included |
No |
| SDR Required Flag |
N |
| SellingPoint01 |
Direct fit for the 2006-2011 Honda Civic Si |
| SellingPoint02 |
Full aluminum construction with durable TIG-welded end tanks |
| SellingPoint03 |
Features a two-row, 1.57-in thick brazed aluminum core which provides efficient fluid temperature regulation on the street and track |
| SellingPoint04 |
Polished end tanks provide a stylish upgrade to your engine bay |
| SellingPoint05 |
Includes Magnetic Drain Plug to capture any metallic debris/fragments in your cooling system |
| SellingPoint06 |
Mishimoto Lifetime Warranty |
| SellingPoint07 |
N/A |
| SellingPoint08 |
N/A |
| SellingPoint09 |
N/A |
| SellingPoint1 |
Direct fit for the 2006-2011 Honda Civic Si |
| SellingPoint10 |
N/A |
| SellingPoint11 |
N/A |
| SellingPoint12 |
N/A |
| SellingPoint13 |
N/A |
| SellingPoint14 |
N/A |
| SellingPoint15 |
N/A |
| SellingPoint2 |
Full aluminum construction with durable TIG-welded end tanks |
| SellingPoint3 |
Features a two-row, 1.57-in thick brazed aluminum core which provides efficient fluid temperature regulation on the street and track |
| SellingPoint4 |
Polished end tanks provide a stylish upgrade to your engine bay |
| SellingPoint5 |
Includes Magnetic Drain Plug to capture any metallic debris/fragments in your cooling system |
| SellingPoint6 |
Mishimoto Lifetime Warranty |
| SellingPoint7 |
N/A |
| SellingPoint8 |
N/A |
| SellingPoint9 |
N/A |
| TechSpec Applications |
Honda Civic 1.8L L4 2006-2011--Honda Civic 2.0L L4 2006-2011 |
| TechSpec Chassis Codes |
FG1FG2FA1FA5 |
| TechSpec Core Height (in) |
26.32 |
| TechSpec Core Length (in) |
14.72 |
| TechSpec Core Thickness (in) |
1.57 |
| TechSpec DPI |
2927 |
| TechSpec Drain Plug Thread Size |
M12 x 1.5 |
| TechSpec Engine Codes |
K20z3 |
| TechSpec Fluid Capacity (gal) |
2.03 |
| TechSpec Includes |
Mishimoto Radiator--Magnetic Drain Plug--Mishimoto Lifetime Warranty |
| TechSpec Inlet (in) |
1.25 |
| TechSpec Material |
Aluminum |
| TechSpec Note |
N/A |
| TechSpec Outlet (in) |
1.25 |
| TechSpec Overall Height (in) |
26.8 |
| TechSpec Overall Length (in) |
18.2 |
| TechSpec Overall Width (in) |
2.07 |
| TechSpec Overall Width (ins) |
2.07 |
| TechSpec Rows |
2 |
| Transmission Oil Cooler Fitting Type |
N/A |
| Transmission Oil Cooler Included |
No |
| GTIN |
00748354798890 |
