This Mishimoto Aluminum Transmission Pan is a direct-fit, high-performance upgrade for your 1989-2010 Ford 7.3L, 6.0L and 6.4L Powerstroke. Cast from high-quality aluminum and powder coated Gunmetal Gray, our transmission pan is a robust and long-lasting upgrade for your vehicle's transmission. With a sleek design and bottom ribs, this pan not only adds to the overall aesthetic of your truck but also provides improved cooling performance.----This transmission pan features internal baffles that reduce sloshing and enhance heat dissipation, resulting in smoother transmission performance. Our casting features a precision-machined sealing surface, ready to accept either a factory-style gasket or sealant of your choice (not included). Additionally, the Mishimoto 1989-2010 Ford Powerstroke Aluminum Transmission Pan adds an extra 6.6 quarts of ATF to help maintain optimal transmission operation.----Fed up with the frustration of trying to hold up a transmission pan with one hand while threading the fasteners in with the other? Mishimoto has you covered with pre-installed bolt retainers that hold the fasteners in the pan, allowing you to easily thread the bolts without dropping them on the ground, your head, or worse, that pan of nasty transmission fluid you just drained. Additionally, our pan comes equipped with a magnetic drain plug for easy draining and a 1/8-inch NPT port and plug for temperature sensors to make servicing your transmission and monitoring temperatures a breeze.----This direct-fit upgrade offers affordable durability and helps maintain smooth transmission operation, ensuring a long life for your transmission. Like all Mishimoto products, this transmission pan is backed by the Mishimoto Lifetime Warranty.
- Durable cast-aluminum construction for long-lasting performance
- Increases fluid capacity by 6.6 quarts over the stock transmission pan for more cooling capacity
- Bolt retainers hold fasteners in place for easy installation
Application Summary:
| Year |
Make/Model |
| 2008-2014 |
Ford E-150 |
| 2008-2014 |
Ford E-250 |
| 2003-2005 |
Ford E-350 Club Wagon |
| 1992-1998 |
Ford E-350 Econoline |
| 1992-2002 |
Ford E-350 Econoline Club Wagon |
| 1999-2016 |
Ford E-350 Super Duty |
| 2000-2002 |
Ford Expedition |
| 1999-2010 |
Ford F-250 Super Duty |
| 1999-2004 |
Ford F-350 Super Duty |
| 2008-2010 |
Ford F-350 Super Duty |
| 2000-2004 |
Lincoln Navigator |
| Attributes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Capacity |
6.7 |
| Color |
Gray |
| Configuration |
One-Piece |
| Country of Origin (Primary) |
CN |
| Dipstick Port |
No |
| Drain Plug Included |
Yes |
| Finish |
Powder Coated |
| Gasket Or Seal Included |
No |
| Grade Type |
Performance |
| Hazardous Material Code |
N |
| Install Difficulty |
1 |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Oil Pan Gaskets Included |
No |
| SDR Required Flag |
N |
| SellingPoint01 |
Direct fit for Ford E4OD/4R100/5R110 transmissions |
| SellingPoint02 |
Durable cast-aluminum construction for long-lasting performance |
| SellingPoint03 |
Increases fluid capacity by 6.6 quarts over the stock transmission pan for more cooling capacity |
| SellingPoint04 |
Bolt retainers hold fasteners in place for easy installation |
| SellingPoint05 |
Internal baffles reduce sloshing and enhance heat dissipation for smoother, more efficient transmission operation |
| SellingPoint06 |
1/8-inch NPT port makes adding a temp sensor fast and easy |
| SellingPoint07 |
Precision-machined sealing surface helps prevent leaks |
| SellingPoint08 |
Magnetic drain plug makes servicing your transmission a breeze |
| SellingPoint09 |
Gunmetal gray powder coat finish adds style and function to your truck’s undercarriage |
| SellingPoint10 |
Patent Pending |
| SellingPoint11 |
Mishimoto Lifetime Warranty |
| SellingPoint12 |
N/A |
| SellingPoint13 |
N/A |
| SellingPoint14 |
N/A |
| SellingPoint15 |
N/A |
| TechSpec Applications |
1989-2010 Ford 7.3L, 6.0L, 6.4L Powerstroke E4OD 4R100 5R110 |
| TechSpec Caution |
N/A |
| TechSpec Chassis Codes |
N/A |
| TechSpec Core Construction |
N/A |
| TechSpec Core Height (in) |
N/A |
| TechSpec Core Length (in) |
N/A |
| TechSpec Core Thickness (in) |
N/A |
| TechSpec Engine Codes |
N/A |
| TechSpec Fluid Capacity (qts) |
6.64 (Pan)/ 13.64 (Total E4OD/4R100)/ 12 (Total 5R110) |
| TechSpec Includes |
(1) Cast Aluminum Transmission Pan--(1) Magnetic Drain Plug--(20) Silicone Bolt Retainers--(20) Socket Head Cap Screws w/ Washers--(1) 1/8-in NPT Plug--Mishimoto Lifetime Warranty |
| TechSpec Inlet |
N/A |
| TechSpec Installation Notes |
Drain Plug Torque Spec: 15 lb-ft----A pan gasket is not included with this product. Mishimoto recommends replacing it with OEM Part #F6TZ-7A191-A to ensure leak-free operation. |
| TechSpec Note |
N/A |
| TechSpec Outlet |
N/A |
| TechSpec Overall Height (in) |
N/A |
| TechSpec Overall Length (in) |
N/A |
| TechSpec Overall Width (in) |
N/A |
| TechSpec Rows |
N/A |
| Transmission Filter Included |
No |
